All Specifications
| Panel | |||
|---|---|---|---|
|
Screen size
65''
|
Screen size
75''
|
Screen size
86''
|
Screen size
98''
|
|
Panel type
IPS
|
Panel type
IPS
|
Panel type
IPS
|
Panel type
IPS
|
|
Active area
1428.5 × 803.5 mm
|
Active area
1649.7 × 927.9 mm
|
Active area
1913.0 × 1084.0 mm
|
Active area
2158.85 × 1214.35 mm
|
|
Aspect ratio
16:9
|
Aspect ratio
16:9
|
Aspect ratio
16:9
|
Aspect ratio
16:9
|
|
Resolution
UHD 3840 × 2160 pixels
|
Resolution
UHD 3840 × 2160 pixels
|
Resolution
UHD 3840 × 2160 pixels
|
Resolution
UHD 3840 × 2160 pixels
|
|
Response time
8 ms
|
Response time
8 ms
|
Response time
8 ms
|
Response time
8 ms
|
|
Color depth
10-bit
|
Color depth
10-bit
|
Color depth
10-bit
|
Color depth
10-bit
|
|
Orientation
Landscape
|
Orientation
Landscape
|
Orientation
Landscape
|
Orientation
Landscape
|
|
Operation hours
18 hours / 7 days
|
Operation hours
18 hours / 7 days
|
Operation hours
18 hours / 7 days
|
Operation hours
18 hours / 7 days
|
|
Panel brightness (typical)
400 nits
|
Panel brightness (typical)
400 nits
|
Panel brightness (typical)
400 nits
|
Panel brightness (typical)
400 nits
|
|
Contrast ratio (typical)
1200:1
|
Contrast ratio (typical)
1200:1
|
Contrast ratio (typical)
1200:1
|
Contrast ratio (typical)
1200:1
|
|
Dynamic contrast ratio
30,000:1
|
Dynamic contrast ratio
30,000:1
|
Dynamic contrast ratio
30,000:1
|
Dynamic contrast ratio
30,000:1
|
|
Color gamut
72% NTSC
|
Color gamut
72% NTSC
|
Color gamut
72% NTSC
|
Color gamut
72% NTSC
|
|
Light life (typical)
50,000 hrs
|
Light life (typical)
50,000 hrs
|
Light life (typical)
50,000 hrs
|
Light life (typical)
50,000 hrs
|
| Glass | |||
|
Anti-glare coating
Yes
|
Anti-glare coating
Yes
|
Anti-glare coating
Yes
|
Anti-glare coating
Yes
|
|
Hardness
9H tempered
|
Hardness
9H tempered
|
Hardness
9H tempered
|
Hardness
9H tempered
|
| Touch screen | |||
|
Touch technology
Infrared touch
|
Touch technology
Infrared touch
|
Touch technology
Infrared touch
|
Touch technology
Infrared touch
|
|
Touch points
up to 40
|
Touch points
up to 40
|
Touch points
up to 40
|
Touch points
up to 40
|
|
Response time
< 10 ms
|
Response time
< 10 ms
|
Response time
< 10 ms
|
Response time
< 10 ms
|
| System | |||
|
Memory | Storage
4GB I 32GB
|
Memory | Storage
4GB I 32GB
|
Memory | Storage
4GB I 32GB
|
Memory | Storage
4GB I 32GB
|
|
OS
Android 11.0
|
OS
Android 11.0
|
OS
Android 11.0
|
OS
Android 11.0
|
|
GPU
G52 MP2
|
GPU
G52 MP2
|
GPU
G52 MP2
|
GPU
G52 MP2
|
|
CPU
A55 × 4
|
CPU
A55 × 4
|
CPU
A55 × 4
|
CPU
A55 × 4
|
| Connectivity | |||
|
Video Graphics Array (VGA)
1 | 0
|
Video Graphics Array (VGA)
1 | 0
|
Video Graphics Array (VGA)
1 | 0
|
Video Graphics Array (VGA)
1 | 0
|
|
HDMI (in | out)
3 × HDMI 2.0 | 1 × HDMI 2.0
|
HDMI (in | out)
3 × HDMI 2.0 | 1 × HDMI 2.0
|
HDMI (in | out)
3 × HDMI 2.0 | 1 × HDMI 2.0
|
HDMI (in | out)
3 × HDMI 2.0 | 1 × HDMI 2.0
|
|
USB-A
4 ×3.0 + 2 x 2.0
|
USB-A
4 ×3.0 + 2 x 2.0
|
USB-A
4 ×3.0 + 2 x 2.0
|
USB-A
4 ×3.0 + 2 x 2.0
|
|
USB-C
1 × 3.0 (PD 65 W)
|
USB-C
1 × 3.0
|
USB-C
1 × 3.0 (PD 65 W)
|
USB-C
1 × 3.0 (PD 65 W)
|
|
USB-B (for touch)
1 × 3.0 + 1 × 2.0
|
USB-B (for touch)
1 × 3.0 + 1 × 2.0
|
USB-B (for touch)
1 × 3.0 + 1 × 2.0
|
USB-B (for touch)
1 × 3.0 + 1 × 2.0
|
|
3.5 mm Line in (1)
PC Audio × 1
|
3.5 mm Line in (1)
PC Audio × 1
|
3.5 mm Line in (1)
PC Audio × 1
|
3.5 mm Line in (1)
PC Audio × 1
|
|
3.5 mm Line out
Earphone × 1
|
3.5 mm Line out
Earphone × 1
|
3.5 mm Line out
Earphone × 1
|
3.5 mm Line out
Earphone × 1
|
|
Slot-in PC (OPS)
1
|
Slot-in PC (OPS)
1
|
Slot-in PC (OPS)
1
|
Slot-in PC (OPS)
1
|
|
SPDIF (in | out)
0 | 1 (optical)
|
SPDIF (in | out)
0 | 1 (optical)
|
SPDIF (in | out)
0 | 1 (optical)
|
SPDIF (in | out)
0 | 1 (optical)
|
|
Ethernet LAN
10 / 100 / 1000 Mbps (Android), 10 / 100 / 1000 Mbps (OPS) × 2
|
Ethernet LAN
10 / 100 / 1000 Mbps (Android), 10 / 100 / 1000 Mbps (OPS) × 2
|
Ethernet LAN
10 / 100 / 1000 Mbps (Android), 10 / 100 / 1000 Mbps (OPS) × 2
|
Ethernet LAN
10 / 100 / 1000 Mbps (Android), 10 / 100 / 1000 Mbps (OPS) × 2
|
|
RS-232
1 | 0
|
RS-232
1 | 0
|
RS-232
1 | 0
|
RS-232
1 | 0
|
| Built-in peripherals | |||
|
Speaker
2 × 16 W
|
Speaker
2 × 16 W
|
Speaker
2 × 16 W
|
Speaker
2 × 16 W
|
| Power | |||
|
ENERGY STAR®
Yes
|
ENERGY STAR®
Yes
|
ENERGY STAR®
Yes
|
ENERGY STAR®
|
|
Power
AC 100-240V 50/60Hz
|
Power
AC 100-240V 50/60Hz
|
Power
AC 100-240V 50/60Hz
|
Power
AC 100-240V 50/60Hz
|
|
Standby power consumption
<0.5 W
|
Standby power consumption
<0.5 W
|
Standby power consumption
<0.5 W
|
Standby power consumption
<0.5 W
|
|
Typical power consumption
82.0 W
|
Typical power consumption
98.1 W
|
Typical power consumption
135.1 W
|
Typical power consumption
183.4 W
|
| Physical | |||
|
Dimensions (W x H x D)
1488.3 × 896.6 × 87.5 mm (58.6 × 35.3 × 3.4 inch)
|
Dimensions (W x H x D)
1709.4 × 1020.2 × 87.7 mm (67.3 × 40.2 × 3.5 inch)
|
Dimensions (W x H x D)
1957 × 1159.9 × 99.7 mm (77.0 × 45.7 × 3.9 inch)
|
Dimensions (W x H x D)
2244.7 × 1323.2 × 89.5 mm ( 88.4 × 52.1 × 3.5 inch)
|
|
Shipping dimensions (W x H x D)
1628 × 208 × 1005 mm (64.1 × 8.2 × 39.6 inch)
|
Shipping dimensions (W x H x D)
1863 × 225 × 1140 mm (73.3 × 8.9 × 44.9 inch)
|
Shipping dimensions (W x H x D)
2110 × 225 × 1283 mm (83.1 × 8.9 × 50.5 inch)
|
Shipping dimensions (W x H x D)
2406 × 1474 × 280 mm (94.7 × 58.0 × 11.0 inch)
|
|
Weight (product I shipping)
36.1 kg | 46.1 kg ( 79.5 lbs | 101.5 lbs)
|
Weight (product I shipping)
48.2 kg | 61.9 kg (106.2 lbs | 136.4 lbs)
|
Weight (product I shipping)
59.9 kg | 76.6 kg (131.9 lbs | 168.9 lbs)
|
Weight (product I shipping)
99.6 kg I 129.1 kg ( 219.6 lbs I 284.6 lbs )
|
|
Mount (screws)
VESA 600 × 400 mm (4 × M8 × 25L)
|
Mount (screws)
VESA 800 × 400 mm ( 4 × M8 × 25L)
|
Mount (screws)
VESA 800 × 600 mm (4 × M8 × 25L)
|
Mount (screws)
VESA 800 × 600 mm (4 × M8 × 25L)
|
| Environment | |||
|
Operating temperature
0°C ~ 40°C | 32°F ~ 104°F
|
Operating temperature
0°C ~ 40°C | 32°F ~ 104°F
|
Operating temperature
0°C ~ 40°C | 32°F ~ 104°F
|
Operating temperature
0°C ~ 40°C | 32°F ~ 104°F
|
|
Storage temperature
-20°C ~ 60°C | -4°F ~ 140°F
|
Storage temperature
-20°C ~ 60°C | -4°F ~ 140°F
|
Storage temperature
-20°C ~ 60°C | -4°F ~ 140°F
|
Storage temperature
-20°C ~ 60°C | -4°F ~ 140°F
|
|
Storage humidity
10% ~ 90% RH Non-Condensing
|
Storage humidity
10% ~ 90% RH Non-Condensing
|
Storage humidity
10% ~ 90% RH Non-Condensing
|
Storage humidity
10% ~ 90% RH Non-Condensing
|
|
Operating humidity
10% ~ 90% RH non-condensing
|
Operating humidity
10% ~ 90% RH non-condensing
|
Operating humidity
10% ~ 90% RH non-condensing
|
Operating humidity
10% ~ 90% RH non-condensing
|
| Software | |||
|
Whiteboarding
EZWrite 6.0
|
Whiteboarding
EZWrite 6.0
|
Whiteboarding
EZWrite 6.0
|
Whiteboarding
EZWrite 6.0
|
|
Wireless screen sharing
InstaShare 2
|
Wireless screen sharing
InstaShare 2
|
Wireless screen sharing
InstaShare 2
|
Wireless screen sharing
InstaShare 2
|
|
Device management
DMS
|
Device management
DMS
|
Device management
DMS
|
Device management
DMS
|
|
Account management
AMS
|
Account management
AMS
|
Account management
AMS
|
Account management
AMS
|
|
Quick access tool
Floating Tool
|
Quick access tool
Floating Tool
|
Quick access tool
Floating Tool
|
Quick access tool
Floating Tool
|
|
Broadcast system
X-Sign Broadcast
|
Broadcast system
X-Sign Broadcast
|
Broadcast system
X-Sign Broadcast
|
Broadcast system
X-Sign Broadcast
|
| Accessories | |||
|
Cables
1 × VGA (3 m | 9.8 ft), 1 × HDMI (3 m | 9.8 ft), 1 × USB-B for touch (3 m | 9.8 ft), 1 × USB-C (1.5 m | 4.9 ft)
|
Cables
1 × VGA (3 m | 9.8 ft), 1 × HDMI (3 m | 9.8 ft), 1 × USB-B for touch (3 m | 9.8 ft), 1 × USB-C (1.5 m | 4.9 ft)
|
Cables
1 × VGA (3 m | 9.8 ft), 1 × HDMI (3 m | 9.8 ft), 1 × USB-B for touch (3 m | 9.8 ft), 1 × USB-C (1.5 m | 4.9 ft)
|
Cables
1 × VGA (3 m | 9.8 ft), 1 × HDMI (3 m | 9.8 ft), 1 × USB-B for touch (3 m | 9.8 ft), 1 × USB-C (1.5 m | 4.9 ft)
|
|
Wall Mount (with shipment)
1
|
Wall Mount (with shipment)
1
|
Wall Mount (with shipment)
1
|
Wall Mount (with shipment)
1
|
|
Stylus
2
|
Stylus
2
|
Stylus
2
|
Stylus
2
|
|
Remote control
1
|
Remote control
1
|
Remote control
1
|
Remote control
1
|
